P0922QS FBM228 Isolation Communication Series

Model:P0922QS FBM228
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

P0922QS FBM228 Isolation Communication Series

Product manual:

P0922QS FBM228 Isolation Communication Series
P0922QS (FBM228) is the FOUNDATION Fieldbus H1 isolated communication module of Foxboro I/A Series DCS, used to connect to field intelligent bus instruments.
Model: P0922QS, corresponding to FBM228, FF H1 bus interface.
4 independent FF H1 ports, 31.25 kbit/s, with a maximum of 16 devices per port.
Electrical isolation between channels ≥ 600V AC, resistant to on-site interference.
Support access to non intrinsic safety/intrinsic safety (via safety barriers) devices.
Powered by 24VDC, with a power consumption of approximately 3.8W.
Support module level redundancy and seamless hot standby switching.
Polarity independent wiring, easy to install.
Compatible with FF standard function blocks and supports on-site control.
Working temperature 0-60 ℃, IP20, G3 anti-corrosion.
Size 102 × 45 × 104mm, weight approximately 0.28kg.
Support hot plugging and online maintenance.
The panel LED displays the status of power, communication, and ports.
Compatible with the entire range of I/A controllers and upper level systems.
Certified by CE, UL, and RoHS.
Used for DCS fieldbus integration in chemical, power, petrochemical and other industries.
P0922QS FBM228 is a key module for I/A system to connect to FF H1 intelligent instrument, with high isolation, multi port, redundancy and reliability as its core.
