P0972ZA FCM100E fieldbus communication module

Model:P0972ZA FCM100E
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

P0972ZA FCM100E fieldbus communication module

Product manual:

P0972ZA FCM100E is a Foxboro I/A Series fiber optic fieldbus communication module that achieves high-speed conversion between 100Mbps Ethernet and fieldbus, providing a reliable communication link between FBM and controller for DCS.
Model: P0972ZA, corresponding to FCM100E, fiber optic fieldbus communication module.
Core function: 100Mbps Ethernet ↔ Bidirectional conversion of fieldbus, connecting ZCP270 and FBM.
Dual speed compatibility: 2Mbps (200 series FBM), 268Kbps (100 series FBM).
Mount capacity: Up to 32 200 series FBMs or 64 100 series FBMs per module.
Redundancy design: Supports dual module thermal redundancy, dual active operation, seamless fault switching.
Communication medium: multimode optical fiber (62.5/125 μ m), resistant to strong electromagnetic interference.
Transmission distance: Fiber optic 3m -2km; 2Mbps fieldbus ≤ 20m, 268Kbps ≤ 1830m.
Power supply: 21-42VDC, maximum power consumption 5W.
Environment: 0 ℃~+70 ℃, 5-95% RH (non condensing), G3 anti-corrosion.
Installation: Standard DIN rail, supports tool free hot plugging.
Size: Approximately 114 × 51.5 × 147mm, weighing approximately 0.3kg.
Diagnosis: LED status light, supporting system management diagnosis.
Protocol: I/A Series Mesh network, configurable with soft addresses.
Certification: CE, UL, RoHS, suitable for harsh environments G3.
Application: DCS fieldbus communication extension for chemical, power, metallurgy, and other industries.
P0972ZA FCM100E is a key module for fieldbus communication in I/A systems, with fiber optic high-speed, redundant and reliable, and strong anti-interference as its core.
