BRC-200 controller board

Model:BRC-200
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

BRC-200 controller board

Product manual:

BRC-200 is a Harmony Bridge Controller under ABB Bailey, belonging to the Symphony/Infi90 distributed control system (DCS) core control board.
Positioning: As the core of system bridging and control, responsible for cross network segment/cross bus data forwarding, real-time control computation, and I/O scheduling.
Processor: 32-bit embedded processor, supporting high-speed real-time computation and multitasking scheduling.
Memory: 1.8MB NVRAM (non-volatile)+7.86MB RAM, used for configuring storage and program execution.
Bus: Compatible with MasterBus 300 and Infi90 buses, supporting redundancy and hot standby.
Communication: Built in multi protocol interfaces, supporting interconnection and interoperability with operation stations, I/O modules, and third-party systems.
Function: Execute control logic, PID regulation, data acquisition, alarm processing, event recording, and redundant switching.
Firmware: Built in 147Bug/Bridge debugging firmware, supporting online diagnosis, program download, and fault location.
Hardware: Standard VME 6U single slot structure, compatible with Bailey rack, with status LED and reset button.
Environment: Industrial grade design, working temperature 0-55 ℃, anti electromagnetic interference, suitable for harsh sites such as power plants and petrochemicals.
Redundancy: Supports 1:1 redundancy configuration, fault free switching, ensuring continuous operation of the system.
Programming: Using Bailey Function Code programming, compatible with traditional Infi90 configuration tools.
Application: Widely used in large-scale process automation DCS systems such as power, metallurgy, chemical, papermaking, etc.
Comparison: Compared to BRC-100, BRC-200 has larger memory, faster computation, and is suitable for more complex control scenarios.
Maintenance: Supports online plugging and unplugging, firmware upgrades, configuration backup and recovery, reducing downtime risks.
Compatibility: Seamless integration with I/O modules such as Bailey IMCP01, IMMFP02, and operator stations.
BRC-200, with high reliability, strong communication, and large memory, has become a key bridge controller connecting the control layer and the field layer in the Infi90 system.
