IIMCP02 Multi bus Communication Processor

Model:IIMCP02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

IIMCP02 Multi bus Communication Processor

Product manual:

IIMCP02 is the Multibus Communication Processor for ABB Bailey Infi90/Net90 systems, serving as the communication hub for cross bus data exchange and communication scheduling.
Positioning: Infi90 system core communication hub, realizing high-speed data exchange between controller, operator station, I/O and fieldbus.
Core functions: Multi bus data routing, communication scheduling, data caching, verification and transmission management, reducing the load on the main controller.
Processor: 32-bit high-performance processor, supporting multitasking parallel communication processing.
Bus protocol: Native support for system buses such as Infi Net, Multibus, RS-485, etc., with a maximum data rate of 10Mbps.
Interface: 50 pin card edge connector, compatible with Infi90 standard 6U rack, supports hot swapping.
Power supply: Powered by the system backplane DC (18-36VDC), no independent power supply is required.
Redundancy: Supports N+1 redundancy configuration, automatic fault switching, and ensures uninterrupted communication.
Diagnosis: Built in fault diagnosis and status monitoring, LED indicates normal/fault/communication status.
Compatibility: Seamless compatibility with Infi90, Net90, Symphony Harmony systems.
Physics: Size approximately 35.6 × 5.1 × 20.3cm, weight 0.6kg, natural convection heat dissipation.
Environment: Working temperature 0-70 ℃, humidity 5-95% RH (no condensation), anti vibration 2g, anti impact 15g.
Application: Large scale DCS communication core for power, petrochemical, metallurgy, papermaking, etc., ensuring real-time interconnection of the system.
Upgrade: Upgraded to the early MCP module, with comprehensive improvements in bandwidth, stability, and redundancy capabilities.
Maintenance: Supports online diagnosis, firmware updates, and fault replacement, making maintenance convenient.
Typical networking: Cooperate with IIMCP01/IMCPM02 to build a redundant communication network for the entire system.
IIMCP02, with its high speed, high reliability, and multi bus compatibility, has become the core guarantee for communication in Infi90 systems.
