IEPDF02 power supply board

Model:IEPDF02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

IEPDF02 power supply board

Product manual:

IEPDF02 is a power board of ABB Bailey Infi90/Symphony Harmony series, providing auxiliary power supply and power management for the internal system.
Positioning: The internal auxiliary power board of Infi90 system provides secondary regulated power supply for control board, communication module, etc.
Input: Receive DC bus input from the main power supply of the system (such as IEPAS02), with a voltage range of 18-36VDC.
Output: Multiple isolated DC (+5V, ± 12V, 24VDC) to meet the low-power power supply requirements at the board level.
Power: Rated power of 50-80W, compatible with low-power units within the system for power supply.
Isolation: Electrical isolation of input and output to suppress interference and improve system stability.
Protection: Integrated overvoltage, overcurrent, short circuit, and over temperature protection, automatically shuts off the output in case of abnormalities.
Structure: Standard Infi90 6U single slot card, compatible with Bailey rack, easy to install.
Status: Equipped with LED indicator lights, visually displaying normal/fault/undervoltage status.
Redundancy: It can form redundant power supply with the same type of board to improve system availability.
Compatibility: Seamless compatibility with Infi90, Net90, and Symphony Harmony system architectures.
Hot swappable: Supports online plugging and unplugging, maintenance does not require downtime.
Environment: Operating temperature range of 0-55 ℃, suitable for industrial sites such as power plants, petrochemicals, and metallurgy.
Positioning: Different from IEPAS02 (system main power supply), IEPDF02 is a board level auxiliary power supply.
Application: Provide stable auxiliary power supply for core control boards such as BRC-200 and IMMFP.
Maintenance: Supports firmware diagnosis, voltage calibration, and fault replacement to ensure long-term system operation.
IEPDF02, with its high integration, strong isolation, and multiple protections, has become a key auxiliary module for internal power supply in Infi90 systems.
